♪ Your Music 愉耳樂器♪山葉Yamaha HS8 主動式 監聽喇叭 八吋 公司貨一年保固
二音路低音反射式雙擴大機近場錄音室監聽喇叭，配備8”錐形低音單體和1”半球形高音單體
- 二音路低音反射式雙擴大機近場錄音室監聽喇叭，配備8”錐形低音單體和1”半球形高音單體
- 38Hz - 30kHz 頻率響應, 47Hz - 24kHz 頻率響應
- 75W LF 加上 45W HF 雙擴大系統提供高效能的120W輸出
- ROOM CONTROL及HIGH TRIM 反應控制
- XLR和TRS phone jack 輸入端能接收平衡或非平衡信號
| HS8 八吋二音路主動式監聽 | HS5 | ||
|---|---|---|---|
| HS8 八吋二音路主動式監聽 | HS5 | ||
|---|---|---|---|
| 一般規格 | |||
| 揚聲器種類 | 2-way bi-amp powered studio monitor | 2-way bi-amp powered studio monitor | |
| Frequency response (-10dB) | 38Hz - 30kHz | 54Hz - 30kHz | |
| Frequency response (-3dB) | 47Hz - 24kHz | 74Hz - 24kHz | |
| 元件 | LF | 8" cone | 5" cone |
| HF | 1" dome | 1" dome | |
| 跨功能鍵 | 2kHz | 2kHz | |
| 輸出電源 | 120W (LF:75W, HF:45W) | 70W (LF:45W, HF:25W) | |
| 輸入靈敏度 | -10 dBu/10k ohms | -10 dBu/10k ohms | |
| I/O 連接器 | XLR3-31 type (balanced), PHONE (balanced) | XLR3-31 type (balanced), PHONE (balanced) | |
| Indicators | Power ON (White LED) | Power ON (White LED) | |
| 耗電量 | 60W | 45W | |
| 型狀 | Bass-reflex type | Bass-reflex type | |
| 機櫃材質 | MDF | MDF | |
| 尺寸 | 寬 | 250mm (9-13/16") | 170mm (6-11/16") |
| 高 | 390mm (15-3/8") | 285mm (11-1/4") | |
| 深 | 334mm (13-1/8") | 222mm (8-3/4") | |
| 淨重 | 10.2kg (22.5 lbs.) | 5.3kg (11.7 lbs.) | |
| 配件 | Owner's Manual, Power cord | Owner's Manual, Power cord | |
| Packaging | Single | Single | |
| 其他 | LEVEL control (+4dB/center click) , EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz) | LEVEL control (+4dB/center click) , EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz) | |
